Plan Details
Description
This ranch home plan features a split bedroom floor plan with spacious common areas. A front covered porch invites you into this cozy rustic house plan. The large grand room allows natural light to flow through with a wall of windows. The spacious kitchen features ample amounts of counter space perfect for entertaining. The master suite has a trey ceiling, sitting room with bay window, and large walk-in closet. Many windows provide warmth and natural light throughout this beautiful home. A full basement plan allows for ample storage and room to grow. We offer floor plan modifications on all of our rustic house plan designs. Have a question about any of our house plans, call us at 770-614-3239.
What's Included In the plan
1. Exterior elevations – Included are front, rear, left and right side views of the exterior of the house. Exterior materials, construction details and measurements are also noted.
2. Foundation Plan – Includes layout of foundation support walls, plus excavated and unexcavated areas, if applicable.
3. Detailed Floor Plans – These plans show the layout of each floor of the house, including room dimensions, window and doors sizes and keys for cross section details provided later in the plans. Engineered floor joist, ceiling joist and roof plans are not included in some plans. Local engineers or manufacturing engineers are widely available to supply the services that apply to local geographic conditions.
4. Interior Details – These drawings show the specific details and design of special interior features.
5. Roof Plan – Includes the overall layout for roof construction. If trusses are used, we recommend using a local truss manufacturer to ensure compliance with local codes and regulations.
6. Cross Section Details – Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Exterior details such as railing and banding may also be shown.
7. Electrical – Electrical floor plan schematics for 1st and 2nd floors.
Additional Information
TOTAL SQFT | 2282 |
1ST FLOOR | 2282 |
GARAGE | 481 |
BATHS | 2 |
BEDS | 3 |
MASTER BEDROOM | Master Down |
WIDTH | 80' 8" |
DEPTH | 53' 6" |
W REF | 80, 81 |
D REF | 53, 54 |
