Plan 4243 Mon Chateau Manor House Plan

4
Bedrooms
4
Bathrooms
4395
Square Ft
2
Stories

Regular price $2,395.00 USD
Regular price Sale price $2,395.00 USD
Sale Sold out

LOW price
guarantee

Find A Lower Price And We'll Beat It
By 10%

Modify This Plan

Need to make changes to this home plan? We will deliver you a free price quote within 2 to 4 business days.

Edit Your Plan
1stFLOORPLAN 03257
2ndFLOORPLAN 03257
Reverse image
NOTE: If you purchase this plan in reverse, please select "readable version" or "mirror reverse" under Options above.

Description

Derived from our award winning house plan The Chateau Lafayette the European style house plan the Mon Chateau Manor is a popular home plan choice for the discriminating homeowner. The master bedroom located on the first floor shares a covered screened porch with the hearth room and the grand room. The large gourmet kitchen opens to the hearth room including a fireplace and the sun room/ breakfast room. The second floor consists of three additional bedrooms, an optional fourth bedroom or bonus room and an optional media room. This home plan offers formal and informal areas for every occasion. Vaulted, coffered and tray ceilings add beauty to rooms throughout this spectacular home. We offer floor plan modifications on all of our European style house plan designs.

What's Included In the plan

1. Exterior elevations – Included are front, rear, left and right side views of the exterior of the house. Exterior materials, construction details and measurements are also noted.

2. Foundation Plan – Includes layout of foundation support walls, plus excavated and unexcavated areas, if applicable.

3. Detailed Floor Plans – These plans show the layout of each floor of the house, including room dimensions, window and doors sizes and keys for cross section details provided later in the plans. Engineered floor joist, ceiling joist and roof plans are not included in some plans. Local engineers or manufacturing engineers are widely available to supply the services that apply to local geographic conditions.

4. Interior Details – These drawings show the specific details and design of special interior features.

5. Roof Plan – Includes the overall layout for roof construction. If trusses are used, we recommend using a local truss manufacturer to ensure compliance with local codes and regulations.

6. Cross Section Details – Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Exterior details such as railing and banding may also be shown.

7. Electrical – Electrical floor plan schematics for 1st and 2nd floors.

Additional Information

TOTAL SQFT 4395
1ST FLOOR 3239
2ND FLOOR 1156
BATHS 4
BEDS 4
HALF BATHS 1
MASTER BEDROOM Master Down
WIDTH 79' 6"
DEPTH 66' 7"
W REF 79, 80
D REF 66, 67
