Plan 7465 Timber Bridge Cottage House Plan
Find A Lower Price And We'll Beat It
The exterior of this alluring rustic mountain cottage house plan is comprised of shake, stone and rough sawn timbers. Located on the main floor is the master suite and three bedrooms. The lodge room centrally located extends to the kitchen and casual dining. This desirable courtyard plan has a covered porch with a fireplace.The ascending two story vaulted lodge room allows a bounty of natural light. We offer floor plan modifications on all of our rustic cottage house plans.
What's Included In the plan
1. Exterior elevations – Included are front, rear, left and right side views of the exterior of the house. Exterior materials, construction details and measurements are also noted.
2. Foundation Plan – Includes layout of foundation support walls, plus excavated and unexcavated areas, if applicable.
3. Detailed Floor Plans – These plans show the layout of each floor of the house, including room dimensions, window and doors sizes and keys for cross section details provided later in the plans. Engineered floor joist, ceiling joist and roof plans are not included in some plans. Local engineers or manufacturing engineers are widely available to supply the services that apply to local geographic conditions.
4. Interior Details – These drawings show the specific details and design of special interior features.
5. Roof Plan – Includes the overall layout for roof construction. If trusses are used, we recommend using a local truss manufacturer to ensure compliance with local codes and regulations.
6. Cross Section Details – Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Exterior details such as railing and banding may also be shown.
7. Electrical – Electrical floor plan schematics for 1st and 2nd floors.
|MASTER BEDROOM||Master Down|
|W REF||53, 54|
|D REF||84, 85|
